Chongqing Haodong Technology Co., Ltd.

Main products: Infrared Catalytic Burner ,Brooder ,BBQ Part

Home/Products/infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)/

infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)

Update time:2022-02-06 07:45:04
Price:$ 20 - $ 50 / Piece
Min Order:100 Piece / Pieces Piece
  • T/T MoneyGram Credit Card PayPal
  • Chongqing China
  • 10000 Piece / Pieces per Month

Basic Info

Brand NameHaodongFeatureAdjustable Height, Easily Assembled, Easily Cleaned, Electronic Pulse IgnitionFinishingGalvanized
Grill TypeGas StovesMetal TypeAluminumModel NumberHD400
Place of OriginChongqing, ChinaSafety DeviceFlame Safety Device

Product Description


Product Description





Company profiles :

----Now Haodong Technology is the first and only manufacture in China who apply rare-earth catalytic combustion technology in infrared burner&heater. It can save 10%-20% energy than non-catalytic type.At the same time, it prolongs the use life of ceramic plate.



infrared honeycomb ceramic plate gas  burner  for BBQ  grill (HD400)

  • Einfrared ceramic plate gas burner parts for BBQ  (HD400) nergy saving:          conversion rate≥90%
  • Environmental friendly:  CO≤80ppm;NOx≤10ppm;CHx≤50ppm
  • Whole combustion:      95% of energy released in the form of infrared ray
  • Flameless & Smokeless
  • Long useful time       ≥11000hr
  • Easily installed
  • Can use Natural Gas and Liquefid Petroleum gas

 Main Purpose of  Infrared Ceramic Burner:

  • Barbeque, Food Baking process and so on. It can save 50% energy when using this kind of products;
  • mainly installed on the innermost firewall of ovens;
  • The combustion front is at right angle to a plane. So it is usually called back furnace;
  • It is widely used in high-grade combined-type oven in North America and in snack car/teppanyaki/duck furnace in China.

*BARBRCUE series infrared catalyticc gas burner

  Specification



MODEL

Dimension

Weight

Gas Type

Heat Output

Power



mm

kg



BTU/h

Kcal/hr

Kw

HD220

220*170*60

0.9

NG/LPG

10000

2520

2.94

HD400

400*80*60

0.7

NG/LPG

9030

2300

2.72

HD538

538*85*65

1.4

NG/LPG

13500

3400

3.9

HD668

668*85*65

1.7

NG/LPG

166000

4180

4.8







HD400                                                                                                   HD538

 infrared honeycomb ceramic plate gas burner for BBQ grill (HD400) infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)

infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)    infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)

HD538                                                                                                               HD220





Usage of technical parameters



Table 1:The use of technical parameters



Items

Technical parameters

Types

natural gas (NG),liquefied petroleum gas (LPG)

Light-off temperature

≥350

complete combustion temperature

≤380

 Heat source temperature

around 850

Baking temperature range

30---850

Wavelength range

1.9μm--15μm

Furnance pressure

natural

 2000pa(NG)/2800pa(LPG)







Table 2:Comparison table for all kinds of energy consumption



Furnace type

 Parameters

          Electronic
            cooker

                Oil furnace

 Coal-fired

furnace

Infrared catalytic

          heaters



Energy requirement



10,000Kcal

10,000Kcal

10,000Kcal

10,000Kcal

Temperature

180

180

180

180

Energy consumption



Electricity(15 kW/h)



Electricity (1Kw/h)+ diesel (2Kg)



Coal (10Kg)



LPG(0.9Kg)

Heating time

20 minutes

40 minutes

90 minutes

          5-8 minutes









The most advantage of our products compared to others:



infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)



Packing Photoes:



infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)infrared honeycomb ceramic plate gas burner for BBQ grill (HD400)

If any need, welcome to contact us freely!!

We'll do our best to serve for you!!

Your satisfaction is our passion!!!

Trade manager:cn1500440252

Whatsapp:+8613883514635
