Base Type | E27 | Brand Name | JAY LIGHTING | Color Temperature(CCT) | Cool White |
---|---|---|---|---|---|
Input Voltage(V) | AC200-240V | LED Light Source | SMD2835 | Lamp Body Material | Aluminum |
Lamp Luminous Efficiency(lm/w) | 130 | Lamp Luminous Flux(lm) | 650 | Lamp Power(W) | 5 |
Model Number | JYQP-05PN | Place of Origin | Guangdong, China | Type | Other, LED BULB |
Working Lifetime(Hour) | 50000 | Working Temperature(℃) | -20, 50 |
JAY LIGHTING SERIES PN
LED High bay Bulb JYQP-05PN
Product Name | LED Bulb |
Input Voltage | AC200-240V |
Power | 5W |
Lamp body Material | Aluminum+ PC |
Driver Mode | Constant Current |
Lamp shade Material | PC shade |
Design Lifespan | 50,000H |
Packing method | Individual Packing |
Color Temperature | 3200K. 5500K, 6500K |
Luminous Flux | 85-95LM/W |
Bean Angel | 180° |
LED chip | Imported chip |
Luminousness | 92% |
Warranty | 2 years |
Package Quantity | 100 PCS |
Application: Project, Mining and any indoor place need energy saving and lighting.
|
LED Bulb PN Series Wholesale Hot-Salling &cheap price LED Bulb
3W 5W 7W 9W 12W
PN Series specfication:
Product Picture | Product Name | Model No. | Power | Lamp Size (mm) | Lamp Base/ Cutout Size (mm) | Specification |
![]() | LED Bulb | JYQP-05PN | 5W | Θ50*H90 | E27 | Input Voltage: AC200-240V Luminous Flux: 100LM/W Chip Type: SMD2835 Samsung Power Factor: 0.5 Beam Angle: 180° CRI: >80 CCT: 6500K/3000K Material: Aluminum+PC Driver: RC driver Warranty: 2 years |
LED Bulb | JYQP-07PN | 7W | Θ55*H100 | E27 | ||
LED Bulb | JYQP-09PN | 9W | Θ60*H110 | E27 | ||
LED Bulb | JYQP-12PN | 12W | Θ65*H125 | E27 |
Our Advantage:
1. Lamp Shade:
The lamp shade is German bayer light disffusion PC material, not easily broken, more safer and durable than ordinary acrylic lamp shade.
2. Good Heat Dissipation
Use the principle of air convection, design for pale hollow, good to heat dissipate, longer light life.
3.Lamp Bead Board
The thermal conductivity used for 2.0 aluminum plate, thick insulation, can pass 3000v high pressure test, can send out smoothly 100-110LM/W.
4.Power Supply
RC power supply,cost-effective and efficient.
Two kinds blister packing.
company profile
Zhongshan JAY Lighting Electrical Equipment Factory belongs to the factory of Shenzhen JAY Lighting Co., Ltd which is a professional lighting company specializing in research, manufacturing and sales of LED High bay bulb and LED Bulb. Our products concern to commercial lighting, hotel lighting, outdoor lighting, home lighting, lamps & drivers, etc.
JAY was established in 2007 and has been one of the leaders in Chinese LED lighting industry.
JAY has been enjoyed a good reputation from internal or overseas, the main exporting markets include Europe, North America and Asia some developed countries and area.
In the future, we will keep going devote to high quality and competitive price LED products and do a good service as your request. Your satisfaction is our pursuit and warmly looks forward to your cooperation.
