Directional Long Distance RFID Reader 2.4GHz Active RFID Reader with Factory Price

Update time：2022-01-27 10:25:58

Price:Negotiable

Min Order:1 Piece / Pieces

Payment Terms:T/T L/C D/P D/A MoneyGram Credit Card PayPal
Port:Guangzhou/ Hong Kong
Supply Ability:50000 Piece / Pieces per Month

Basic Info

Brand Name	DAILY RFID	Model Number	Long Distance RFID Reader

Product Description

Keywords Searching: Long distance 2.4G active RFID directional reader, 2.4G RFID Reader, active integrated reader, long distance RFID reader, directional rfid reader, active directional rfid reader, 2.45ghz rfid reader, vehicle access control rfid reader, RFID reader price,RS232 RFID reader, Ethernet RFID reader.

Technical data

Frequency Band--2.400-2.4835GHz
Reading Range-- 0-200m(adjustable)
Simultaneous Tag Detection—200
Sensitivity-- -95dBm
Waterproof--IP67
Software---development kit of API (C++ and C#)
Communication interfaces-- RS-232, RS-485, Wiegand 26/34,
10/100M Adaptive Ethernet and customized interfaces

Applications

School & cooperation personnel management and positioning
Automatic vehicle identification
Parking management, highway toll collection
Warehousing and logistics
Vehicle Tracking

Specifications

RF Parameters
Operating Frequency	2.4-2.48GHz
Sensitivity	-95dBm
Communication Interfaces	RS-232, 10/100M Adaptive Ethernet
Expansion Interfaces	RS-485 interface, Wiegand 26/34 interfaces
I/O Port	2- channel relays output(optional), 2- channel trigger input(optional)
Firmware Upgrade	Upgrade through Serial Port
Application Software Platform	Provide development kit of API(C++ and C#)
Tag operation
Tag Protocol	Private Protocol
Tag Operating Mode	Compatible with active and passive operating mode tags
Reading Range	0-260m (depend on the tag power output)
Identification Speed	200pcs/s (tag ID)
Anti-confliction	Identifying 300pcs tag at the same time
Mechanical & Electrical performance
Dimensions	315mm×200mm×110mm
Weight	1.7kg
Power Supply	DC5V input
Power Consumption	300mW
Power Isolation	1KV (Except Ethernet data, I/O port)
Operating Temperature	-40°C~+60°C
Storage Temperature	-40°C~+80°C
Humidity	5% ~ 95% (non-condensing)
Waterproof	IP67
Shock Resistance	10~500Hz, 100mm/15g, triaxial
