Product Description

A FRAME LAYER CAGE SYSTEM

It is designed both for open or close house worldwide, especially using widely in tropical country such as Africa, South East Asia and South Asia where the farmers have large scale land for the big poultry farms. The A frame layer cage system is good quality which is certified by ISO9001:2008 with scientific design, efficient working, strong and structure with lower cost through installation service.

CAGE SYSTEM SPECIFICATIONS

Item NO.	cell length	cell depth	cell height	dimension /unit (mm)	cells/unit per set	tier/set	birds per cell/unit/set
A390	390	350	380	1950350380	5/6	3	3/15/90
A4120	390	350	380	1950350380	5/8	4	3/15/120
A396	490	350	380	1960350380	4/6	3	4/16/96
A4128	490	350	380	1960350380	4/8	4	4/16/128
A3120	430	420	410	2150420410	5/6	3	4/20/120
A4160	430	420	410	2150420410	5/8	4	4/20/160
A3150	430	500	430	2150500430	5/6	3	5/25/150
A4200	430	500	430	2150500430	5/8	4	5/25/200

● Both the cage meshes and cage leg support frames materials are the Q235A steel which ensure the cage meshes give enough elasticity to the layer birds and make the chicken feel good for laying eggs;

●Feed troughs: made of PVC ones(100% new material) or the 1.0--1.20mm thick hot galvanized steel sheets with round edge for convenient cleaning, solid and durable design.

AUTOMATIC FEEDING SYSTEM

● Both of the traveling hopper(feeding carts) type and chain feeding system are available.

●The feeding cart connected with the silo by the transverse feeding auger is more popular here. In this system, feed is distributed automatically to the feed carts from the feed silos by the spiral augers located in a pipe with 90-150 mm diameter.

●The auger and chain material are made in South Africa, and a world-wide reputation for quality.

DRINKING SYSTEMS

●It is made up by the square pipes(thickness 2.5mm) or round pipes(thickness 2.0mm) with 360 degree flowing nipple drinkers, water drip cups and water pressure regulators, terminals, splits, water filters makes sure the water is clean and no harmful to the layers.

●The medicator (from France) to farmers, the best quality founded in the worldwide because we are one of the authorized distributors of DOSATRON in China. It ensures the layer birds health during all period.

AUTOMATIC EGG COLLECTION SYSTEM

● It is made up by egg collection machines, egg collection belts (made in Italy) and egg belt hooks. The machines can be made into 2 to 8 tiers. A frame cages also can be equipped with egg conveyor system which can deliver all eggs from different houses to egg storage room.

AUTOMATIC MANURE REMOVAL SYSTEM

●The scraper type manure collection machine is designed for A frame cage systems which has manure pits under the cages. The manure dropping from the cages in the manure pits, and the scraper can collect the manure from the manure pits to the outside of the chicken house. This system is popular design in China market or other countries who want to raise chickens on floor with cages.

A FRAME LAYER CAGE SYSTEM ADVANTAGES

● Saving more cost for farmers because its lower investment as H frame layer cage system because some items of cages also has number of birds is reared per unit of area and it helps in identifying poor producers and prompt cullings;

● It is easy to deliver and install in clients farm and make maintenance, removal of stress factors; easy to control of parasitic disease like coccidiosis and worm infestation;

●Prompt steps to control feed wastage because of the special design feed trough edge with round bottom which designed in order to get best feed efficiency;

●The cage method of housing is ideal for the area of moderated climate conditions where the day temperature in summer is not high or fall too low; the overlap parts is bigger so the chicken house can get much better ventilation, it can be used both in open or close house according clients’ needs.
