Chocolate and candy cooling tunnel Machinery

Update time：2022-03-04 12:23:17

Price:$ 10000 - $ 99999 / Set

Min Order:1 Set / Sets Set

Basic Info

Brand Name	AMC	Model Number	AMC021601	Place of Origin	Jiangsu, China
Type	Other, Cooling processing equipment

Chocolate and candy cooling tunnel Machinery

1.Single transmission belt

2.one ribbonflight and one Wheel scraper

Chocolate and candy cooling tunnel Machinery

1.Adjustable stainless steel triangle transmission band guide plate in the entrance and exit place of tunnel

2.Transmission band driver installed in the bottom of tail end of tunnel

3.Air control regulatory mechanism in front and end

Power supply	14.6kw/380v
Standard refrigerating capacity	21800Kcal/h
Cooling Type	Cooled by Circulating closed centrifugal fan
Time inside the wind tunnel	18-30min
Entrance temperaturer of Tunnel	5 °C -14 °C
Exit temperaturer of Tunnel	0 °C -10 °C
capacity	100 -150kg /h
Weight	4600kg
Outside Dimension	12000 × 1200 × 2000mm
Material:	Frame : A3 carbon steel . All the surface of the machines are covered with SS304

All of the items are made to order ,we can do based on your requirements !
