AMC System Technology (Suzhou) Co., Ltd.

Main products: Cooling Tunnel ,Automatic Conveyor ,Chocolate Machine ,Automatic Equipment

Home/Products/Chocolate and candy cooling tunnel Machinery/

Chocolate and candy cooling tunnel Machinery

Update time:2022-03-04 12:23:17
Price:$ 10000 - $ 99999 / Set
Min Order:1 Set / Sets Set
  • T/T MoneyGram
  • Shanghai port
  • 5 Set / Sets per Month

Basic Info

Brand NameAMCModel NumberAMC021601Place of OriginJiangsu, China
TypeOther, Cooling processing equipment

Product Description


Product Description


Specifications



Chocolate and candy cooling tunnel Machinery

1.Single transmission belt

2.one ribbonflight and one Wheel scraper



 Chocolate and candy cooling tunnel Machinery

1.Adjustable stainless steel triangle transmission band guide plate in the entrance and exit place of tunnel

2.Transmission band driver installed in the bottom of tail end of tunnel

3.Air control regulatory mechanism in front and end

Power supply

14.6kw/380v

Standard refrigerating capacity

  21800Kcal/h

Cooling Type

Cooled by Circulating closed centrifugal fan

Time inside the wind tunnel

18-30min

Entrance temperaturer of Tunnel

5 °C -14 °C

Exit temperaturer of Tunnel

0 °C -10 °C

 capacity

100 -150kg /h

 Weight

4600kg

 Outside Dimension

12000 × 1200 × 2000mm

Material:



Frame : A3 carbon steel .  All the surface of the machines are covered with SS304





Chocolate and candy cooling tunnel MachineryChocolate and candy cooling tunnel MachineryChocolate and candy cooling tunnel MachineryChocolate and candy cooling tunnel Machinery

All of the items are made to order ,we can do based on your requirements !
