Product Description

Delivery Time:7-12 working days after received your payment
Certification:CE

laser cutting machines for cutting wood / engraving cutting machine

Machine features

1> RECI / EFR / CO2 laser tube has a good beam and strong stability, lifetime over 8000 - 10000 hours

2> DSP control panel in English, USB interface, offline or online work, reading U flash

3> Adopts imported HIWIN linear guide rail, with high precision.

4> Adopts Leadshine three - phase stepper motor drive, it’s stable and reliable, and with high precision.

5> Red dot pointer, location system, showing the exact outline.

6> Honey - comb and blade worktable are optional

8> The circulation of water cooling,guarantee the water temperature is constant, extend the service

time of the laser

9> Exclusion of dust and smoke

10> The huff protection, air injector protects lens from heat and exhaust gas

11> The proprietary software supports various files format PLT, BMP, DXF, DST, T100, etc.

12> Supply various options

• Up & down worktable suitable for cutting and engraving on different height materials.

• Rotary systems, suitable for engraving on cylinder materials.

Specification

Model	LXJ9060
Laser	CO2 glass sealed laser tube
Laser power	40W 60W 80W 100W 130W 150W
Work platform size	600 * 900mm
Software	Ruida or Leetro for optional
Engraving speed	0 ~ 1000mm / s
Cutting speed	0 ~ 500mm / s
Worktable	Honey - comb or Knife Slatted platform optional
Precision of positioning	≤ ±0.025mm
Graphic format Supported	The Files which CorelDraw, Photoshop, AutoCAD can identify (BMP, GIF, JPEG, PCX, TGA, TIFF, PLT, CDR, DMG, DXF, PAT, CDT, CLK, DEX, CSL, CMX, AI, WPG, WMF, EMF, CGM, SVG, SVGZ, PCT, FMV, GEM, CMX)
Compatible software	CorelDraw, AutoCAD
Working temperature:	0 - 45 degree C
Motor type:	Stepper Motor
Cooling:	CW3000 or CW5000 or CW5200 Industry Water Chiller
Control Configuration	DSP / USB Interface
Electricity:	220V / 50Hz / 1kva

Applications

♦ Stone Industry marble, granite, stone, artificial stone, white marble etc.

♦ Artcrafts Industry wood, bamboo, elephant's tusk, bone, leather, marble, sea shell etc.

♦ Advertisement Industry double color board, acrylic engraving and cutting, label engraving, advertising signs and board, etc.

♦ Model Industry sand table constructtion model, architecture models, plane model etc.

♦ Packing Industry rubber engraving, plastic, doubling plate, die board cutting etc.

♦ leather and cloth processing Industry compound leather, man-made leather, fabric, fur, toy etc.

Machine photo

Packing | Delivery

1. Lead time Within 7 - 12 working days after receiving payment.

• For standard machines, it would be 7 - 12 working days;

• For non - standard machines and customized machines according to our clients' specific requirements, it would be 12 to 21 working days.

2. Packing Standard Ply - wooden case for exporting, non fumigation.

• All laser machine are packed with standard inner plastic wrap and outer plywood case.

• The inner package would be help to tight all the small parts in the package. And the plywood is firm enough to protect the laser machine during shipping.
