weighting agent of drilling fluids Barite Powder
Share
- T/T L/C D/P D/A MoneyGram
- Tianjin
- 5000 Metric Ton / Metric Tons per Month
Basic Info
| Application | Drilling | BaO Content (%) | - | BaSO4 Content (%) | 90%min |
|---|---|---|---|---|---|
| CaO Content (%) | - | Dimensions | 250mesh-320mesh | Fe2O3 Content (%) | - |
| Largest Crystal | 200mesh | MgO Content (%) | - | Moisture Content (%) | 0.2% |
| Na2O Content (%) | - | SiO2 Content (%) | - | Type | Barite Powder |
| Weight | 4.2g/cc | Whiteness | 93 | ||
Product Description
Product Description
Specifications
weighting agent of drilling fluids Barite
copetitive price and good quality
weighting agent of drilling fluids Barite Powder
| Formula (repeating unit) | BaSO4 |
|---|---|
| Strunz classification | 07.AD.35 |
| Dana classification | 28.03.01.01 |
| Crystal symmetry | Orthorhombic (2/m 2/m 2/m) dipyramidal |
ITEM |
STANDARD |
TEST RESULT |
APPEARANCE | White powder | White powder |
MAIN CONTENT | ≥90.00% | 91.43% |
Density | 4.2-4.3g/cm3 | 4.2 g/cm3 |
Degree of fineness | 250-320 mesh | pass |
Water soluble alkali metal(Ca) | ≤250, mg/L | 230 mg/l |
Viscosity ,mPa•s | Without CaSO4 | ≤125 |
With CaSO4 | ≤125 | |
PH-value of aqueous suspension 100 g/l | 6.5-9.0 | 7.38 |
TEST RESULT | GRADE 7 | pass |
ome 77% worldwide is used as a weighting agent for drilling fluids in oil and gas exploration to suppress high formation pressures and preventblowouts. As a well is drilled, the bit passes through various formations, each with different characteristics. The deeper the hole, the more barite is needed as a percentage of the total mud mix. An additional benefit of barite is that it is non-magnetic and thus does not interfere with magnetic measurements taken in the borehole, either during logging-while-drilling or in separate drill hole logging. Barite used for drilling petroleum wells can be black, blue, brown or gray depending on the ore body. The barite is finely ground so that at least 97% of the material, by weight, can pass through a 200-mesh (75-μm) screen, and no more than 30%, by weight, can be less than 6 μm diameter. The ground barite also must be dense enough so that its specific gravity is 4.2 or greater, soft enough to not damage the bearings of a tricone drill bit, chemically inert, and containing no more than 250 milligrams per kilogram of soluble alkaline salts.[
