Top Sale in Ghana Automatic Cube Sugar Machine|Cube Sugar Processing Production Line

Update time：2022-02-11 03:50:09

Price:Negotiable

Min Order:1

Payment Terms:T/T Credit Card
Supply Ability:1000 per Month

Product Description

Top Sale in Ghana Automatic Cube Sugar Machine|Cube Sugar Processing Production Line

Product Description

Description of Cube sugar making machine:

The equipment is a kind of cube sugar machine that can achieve automatic rotation, automatic frequency control and continuous briquetting, and is mainly applied in the briquetting of

sugar with cube shapes.

It has many specifications such as 2*2*2cm and 5*5*5cm. It can be adjust according to your

requirements. The equipment is applied in the briquetting of sugar particles with less than 19% water and 100% sugar.

The infrared drying oven, flat conveyor, automatic sugar block sorting machine, automatic packaging machine, and jet coding machine are needed to form a production line when the cube sugar machine is put into use.

Technical parameters of Cube sugar making machine:

Name	Technical parameter
The sugar grinding mil	Model:UT-200 Application field:Pharmaceutical, chemical, food Spindle speed 3310(r/min) Motor power:4kw Weight:260kg Capacity:300-500kg/h Feed particle size≤1-5mm The discharging granularity:20-150mm
blender	Model:UT-80 Application field: Pharmaceutical, chemical, food Motor power:2.2kw Weight:120kg Capacity:200kg/h The discharging granularity:20-150mm
feeding machine	Model:UT-100 Application field: Pharmaceutical Motor power:0.75kw Weight:150kg Bin volume:100L Throughput:3 Cubic/h
Molding machine	Model:UT-200 Application: coffee of sugar Motor power:3.0kw Weight:1100kg Capacity:200-300kg/h
Drying oven	Model:UT-280 Motor:18kw Weight:450kg Working temperature: 100-400° Throughput:400kg/h
