Inverter ac dc tig welding machines with cooling fans
Share
- T/T MoneyGram Credit Card
- Ningbo/Shanghai China
- 10000 Set / Sets per Month
Basic Info
| After-sales Service Provided | Engineers available to service machinery overseas | Arc Current | AC:10A,DC:5A | Brand Name | ANDELI Or OEM |
|---|---|---|---|---|---|
| Certification | CE | Condition | New | Dimensions | 440x210x430mm |
| Model Number | AD DC TIG 210 | Motor Type | Other, AC/DC Aluminium Welding Machine | Pilot Arc Current | 200A |
| Place of Origin | Zhejiang, China | Power(W) | TIG:5KVA,MMA:7.5KVA | Pulse Frequency | 50/60HZ |
| Rated Duty Cycle | 40% | Usage | Home and Industrail application | Voltage | 220/230/240V |
| Warranty | 2 Years | ||||
Product Description
Product Description
Inverter ac dc tig welding machines with cooling fan
IGBT INVERTER AC/DC TIG+MMA 1PH 220V
1.IGBT advanced double inverter technology
2. Single phase power supply
3. Light Weight
4.HF arc start for TIG ,ARC force for MMA
5.2T/4T and pulse control function for TIG
6.AC/DC pulse TIG suitable for steel ,stainless steel ,aluminum
7.Digital display and current preset adjusting
8.Can be with foot pedal
9. 9 Memory deposit
10. low sound fan ,no interference to the home applyance
| Model | AC/DC 170 | AC/DC TIG 200 | AC/DC TIG 210 | |||
| Power Supply Voltage | 1x220/230/240V | |||||
| Frequency | 50/60 | |||||
| TIG | MMA | TIG | MMA | TIG | MMA | |
| Rated Input Power(kw) | 3.3 | 5.4 | 4.5 | 7 | 5 | 7.2 |
| Rated input Current(A) | 22 | 35.3 | 30.1 | 46.8 | 5-200A | 5-210A |
| Duty cycle (40°C,10min) | AC35% 170A | DC 35% 160A | AC 35% 200A | DC 35% 160A | AC35% 210A | DC 35% 160 |
| AC 60% 150A | DC 60% 110A | AC 60% 150A | DC 60% 110A | AC 60% 150A | DC 60% 110A | |
| AC 100% 120A | DC 100% 90A | AC 100% 120A | DC 100% 90A | AC 100% 120A | DC 100% 90A | |
| No load voltage (V) | 66 | |||||
| Start/welding/crater current Range (A) | AC 10-170 ;DC 5-170 | AC 10-200 ;DC 5-200 | AC 10-210 ;DC 5-210 | |||
| Up Slope/down Slope Flow(S) | 0-10S | |||||
| Pre/post Flow(S) | 0.1-9.9/0.5-25 | |||||
| Power factor | 0.75 | |||||
| Clearance Effect(AC TIG) % | -35/+35 | |||||
| Pulse Frequency(hz) | 0.5-250 | |||||
| AC frequency (Hz) | 0.5-200 | |||||
| Pulse width Range(%) | 20-80 | |||||
| Net Weight (Kg) | 17 | 17 | 17 | |||
| Dimension(mm) | 500x230x450 | |||||
| Protection Class | IP 23 | |||||
| Insulation Class | F | |||||
Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours.
Our salesmen will reply your inquiry within 24 hours. Any order is welcome. If you like to be our agent in your country, we can give you any support on the technique & other aspects.
If you have any questions ,please contact with us.
