Mechanical/digital bitumen flow meter

Specifications

1 Bitumen flow meter

2 Meter kerosene,diesel,bitume

3 Corrosion resistent flow meter

4 Digital display available

LC Series oval gear positive displacement bitumen flow meter , the main type of positive displacement flow meters, is used to meter fluid flow in the closed pipeline  .

Advantage

Good adaptation , easy installation and essentially independant of  temperature, pressure change .



Technical Data

Medium temperature:

LC-A/B/E(-20°c~+100°c)

In high temperature adjustment, with high temperature heat tube can reach 280 degrees

( 1)normal cast iron type(A), Steel type(E),Stainless steel type(B)

Type	A	E	B
Pressure(Mpa)	1.6	2.5,4.0,6.4	1.6
Temperature(°C)	-20~280	-20~280	-20~280
Viscosity(mpa.s)	2~200	2~200	2~200



3 Flow range(m³/h)

Type	A	A	E	E	B	B
Accuracy	0.5	0.2	0.5	0.2	0.5	0.2
Diameter(10mm)	0.08~0.4	0.1~0.4	0.08~0.4	0.1~0.4	0.1~0.5	0.1~0.5
Diameter(15mm)	0.25~1.5	0.3~1.5	0.25~1.5	0.3~1.5	0.3~1.5	0.3~1.5
Diameter(20mm)	0.5~3	0.6~3	0.5~3	0.6~3	0.6~3	0.6~3
Diameter(25mm)	1~6	1.2~6	1~6	1.2~6	1.2~6	1.2~6
Diameter(40mm)	2.5~15	3~15	2.5~15	3~15	3~15	3~15
Diameter(50mm)	4~24	4.8~24	4~24	4.8~24	4.8~24	4.8~24
Diameter(80mm)	10~60	12~60	10~60	12~60	12~60	12~60
Diameter(100mm)	16~100	20~100	16~100	20~100	20~100	20~100
Diameter(150mm)	32~190	38~190	32~190	38~190	38~190	38~190
Diameter(200mm)	34~340	68~340	34~340	68~340	68~340	68~340



Mechanical display  positive displacement bitumen flow meter





Mechanical gauge betumen flow meter with zero clearing



Mechanical gauge of betumen flow meter with no zero clearing
