ACWU90
CSA C22.2No.51
ACWU90 Cable: A Reliable CSA-Certified Solution for Canadian Power Distribution
In Canadian electrical installations, choosing the right cable is critical for safety, durability, and code compliance.
ACWU90 is a widely used CSA certified armoured cable, specifically designed to meet the requirements of the Canadian Electrical Code (CEC) for demanding environments.
What Is ACWU90 Cable?
ACWU90 is an aluminum conductor, armoured cable with cross-linked polyethylene (XLPE) insulation, rated for 90°C operation.
It is manufactured in accordance with CSA C22.2 No. 51 and approved for use under the Canadian Electrical Code.
The cable features interlocked aluminum armour, which provides both mechanical protection and serves as the equipment bonding conductor, eliminating the need for a separate ground wire.
⸻
Key Construction Features
• Conductors: Compact aluminum conductors
• Insulation: XLPE, rated 90°C (dry and wet locations)
• Armour: Interlocked aluminum armour
• Voltage Rating: 600 V
• Certification: CSA Certified – ACWU90
This construction makes ACWU90 a strong and lightweight alternative to copper armoured cables, especially in larger conductor sizes.
⸻
Typical Applications
ACWU90 cable is commonly used in:
• Service entrances
• Feeders and branch circuits
• Commercial and industrial buildings
• Residential multi-unit buildings
• Exposed or concealed installations
• Dry and wet locations
Its resistance to moisture and heat makes it suitable for both indoor and outdoor installations, where permitted by the CEC.
