Brand Name | YUAO | Certification | CE | Model Number | 300W |
---|---|---|---|---|---|
Mounting | Wall / Window Mount | Operating Voltage | Other, 48VDC | Place of Origin | Shanghai, China |
Type | Cabinet Air Conditioner |
off grid solar air conditioner,grid tied solar air conditioner,solar cabinet air conditioner
1.DC48V air conditioner,48VDC air conditioner,DC air conditioner
2.DC 48V motor , fan , compressor air conditioner ,DC48vcontroller
3.new product can be connect solar photovoltaic electric supply 48vdc system , wind turbine system , battery system .
4.used in electric cabinet , telemucation or communication enclosure cabinet , controller cabinet , battery cabinet cooling.
5.exculsive teachnical of DC48V cabinet air conditioner , and dc48v air conditioner , it is make 100% solar became ture.
cabinet air conditioner(WALL type) | |||
Model NO | EC04-48D | EC06-48D | |
cooling capacity L35/L35 | W | 420 | 680 |
Btu/h | 1194 | 2321 | |
cooling capacity L25/L35 | W | 350 | 460 |
Btu/h | 1194 | 1570 | |
rated input power L35/L35 | W | 190W | 260W |
rated input power L25/L35 | W | 165W | 180W |
rated Current L35/L35 | A | 4 | 3.5 |
rated Current L25/L35 | A | 5.5 | 3.8 |
Grade of Protection | inside | IP54 | |
outside | IP34 | ||
Refrigergerant | R134a | ||
Outside temp | 15°C-52°C | ||
Inside temp | 25°C-40°C | ||
temperature controller set point | °C | temp range 25°C-40 °C factory settings 35°C | |
Noise lever | dB(A) | 58 | 58 |
dimension | D(MM) | 150 | 195 |
W(MM) | 320 | 320 | |
H(MM) | 550 | 550 | |
Weight | Kg | 18 | 24 |
....
