Small saddled tray type AGV-automated guided vehicle
Update time：2022-01-27 22:35:39
Share
Price:Negotiable
Min Order:1
- 0 per Month
Basic Info
| Place of Origin | Guangdong, China | ||||
|---|---|---|---|---|---|
Product Description
Product Description
Specifications
self-own core technologhy, competetive price, reliable quality
Small saddled tray type AGV, one-way operation, small size, flexible transportation. While transporting, it places the commodity in the tray. It reads the landmark instruct through magnetic stripe navigation. It delivers the commodity to the designated spot. When several AGVs are used in cooperation, they can be constituted into an assembly line and form flexible production system instead of stream-lined line.
AGV Driving Route Map Case
Technical parameters
| Overall Dimension | L850*W350*H350(mm) |
| Moving Way | Magnetic stripe navigation |
| Moving Directions | Going ahead, back ,turning to the left and the right, bifurcating |
| Means of Communication | Wireless Local Area Network |
| Driving Mode | Differential driving |
| Driving Power | DC24V |
| Carrying Capacity | 300Kg ,500Kg (or custom made) |
| Model | Small saddled tray type AGV |
| Carrying Capacity | 30-45m/minute(or custom made) |
| Turning Radius | The minimum could be 800mm(the magnetic stripe path lays the radius) |
| Navigation Accuracy | ±10mm |
| Manner of Working | 24hours |
| Climbing Capacity | 3-5° |
| Stop Precision | ±10mm |
| Charge Methods | Manual Charging /Automatic Charging |
| Safety Induction Scope | ≤3m,adjustable,the urgent braking length is less than 20mm |
| Alarm Form | Acousto-optic Alarm |
| Storage Battery | Maintenance free charging, continuous discharge times are more than 300. |
| Safety Protection | The front obstacle detects the sensor + machinery anticollision mechanism double protection |
| Designed Life | More than 10 years |
AGV Frame diagram
Application schematic diagram
