Top-Sales Africa Block Ice Machine for Sudan
Share
- T/T MoneyGram Credit Card
- Guangzhou
- 30 Set / Sets per Month
Basic Info
| After-sales Service Provided | Engineers available to service machinery overseas | Brand Name | CBFI | Capacity | 10 Tons |
|---|---|---|---|---|---|
| Certification | CE | Condition | New | Dimension(L*W*H) | 2500x1200x2000 and 6360x3710x1565mm |
| Ice Shape | Ice Block | Model Number | MB Series | Place of Origin | Guangdong, China |
| Power(W) | 26.6kw | Voltage | 220V/3Ph/60Hz, 380V/3Ph/50Hz | Warranty | 12 month |
| Weight | 2600kg | ||||
Product Description
Product Description
Africa Block Ice Machine
1. Ice block machine have brine design, containerized design and direct evaporate design (use aluminum make ice cans).
2. Ice block machine for producing big block ice, can design each ice block as 2.5kg, 5kg, 10kg, 15kg, 20kg, or 25kg......
3. It is big ice so can keep for long time. For some countries, specially, Africa country the power supply is not steady, so need big ice keep fresh for food or some other things or chilling drinks and water.
4. Daily capacity of ice block machine can be from 1ton to 100tons.
Model | Capacity | Compress Power | Motor Power | Voltage | Frequency | Outer Dimension(mm) | ||
No. | Ton/24h | KW | KW | V | Hz | L×W×H | ||
MB10 | 1.0 | 3.8 | 0.55 | 230/380/415 | 50/60 | 1200 | 1000 | 600 |
MB15 | 1.5 | 5.6 | 0.75 | 230/380/415 | 50/60 | 1600 | 1200 | 800 |
MB20 | 2.0 | 7.5 | 1.5 | 230/380/415 | 50/60 | 1800 | 1200 | 800 |
MB30 | 3.0 | 11.3 | 1.5 | 230/380/415 | 50/60 | 2100 | 1200 | 1000 |
MB40 | 4.0 | 15.0 | 1.5*2 | 230/380/415 | 50/60 | 3000 | 1470 | 1000 |
MB50 | 5.0 | 18.8 | 1.5*2 | 230/380/415 | 50/60 | 4200 | 1470 | 1200 |
MB60 | 6.0 | 22.5 | 1.5*2 | 230/380/415 | 50/60 | 4800 | 1470 | 1200 |
MB80 | 8.0 | 30.0 | 2.0*2 | 230/380/415 | 50/60 | 5700 | 1470 | 1200 |
MB100 | 10.0 | 37.5 | 2.0*2 | 230/380/415 | 50/60 | 7000 | 1680 | 1200 |
MB120 | 12.0 | 45.0 | 2.5*2 | 230/380/415 | 50/60 | 8500 | 1680 | 1200 |
MB150 | 15.0 | 56.3 | 3.0*2 | 230/380/415 | 50/60 | 9800 | 1680 | 1200 |
MB200 | 20.0 | 56.0 | 5.5*2 | 230/380/415 | 50/60 | 11800 | 1680 | 1500 |
Note:
The above information is according to adopt water cooled condenser.
Size of machine is before installation.It didn’t mention size of cooling tower, cooling tower is usually installed in the outside.
Machine running condition: water temperature: 23Centi degree, evaporate temperature:-12Centi degree, condensing temperature 40Centi degree, reference valve under 50Hz power supply. Real production of machine will have a little change according to change of water temperature and ambient temperature.
V.Ice Block Machine Pictures:
This is the complete block ice machine. We will offer you everything of the block ice machine that you need.
The integrated design block ice machine, it can save space and you don't need to do the welding work when the block ice machine arrive at you.
Danmark Danfoss Expansion valve
The cold room to store ice block
