Direct evaporative Ice Block Machine on 1tons per day

Specifications

Automatic Ice Block Maker

1.20feet contianer:5ton

2.40feet container:10ton

3.Block ice:25kg

4.Model:aluminum

MB Series Automatic Ice Block Maker:

Ice block making machine for produce big block ice, can design each ice block as 2.5kg, 5kg, 10kg, 15kg, 20kg, or 25kg......

It is big ice, so can keep for long time. For some country, specialy, Africa country the power supply is not steady, so need big ice keep fresh for food or some other things or chilling drinks and water.



Daily capacity of ice block machine can be from 1ton to 20tons.



Automatic Ice block maker models for your reference:



Model	Capacity	Compress Power	Motor Power	Voltage	Frequency	Outer Dimension(mm)
No.	Ton/24h	KW	KW	V	Hz	L×W×H
MB10	1.0	3.8	0.55	230/380/415	50/60	1200	1000	600
MB15	1.5	5.6	0.75	230/380/415	50/60	1600	1200	800
MB20	2.0	7.5	1.5	230/380/415	50/60	1800	1200	800
MB30	3.0	11.3	1.5	230/380/415	50/60	2100	1200	1000
MB40	4.0	15.0	1.5*2	230/380/415	50/60	3000	1470	1000
MB50	5.0	18.8	1.5*2	230/380/415	50/60	4200	1470	1200
MB60	6.0	22.5	1.5*2	230/380/415	50/60	4800	1470	1200
MB80	8.0	30.0	2.0*2	230/380/415	50/60	5700	1470	1200
MB100	10.0	37.5	2.0*2	230/380/415	50/60	7000	1680	1200
MB120	12.0	45.0	2.5*2	230/380/415	50/60	8500	1680	1200
MB150	15.0	56.3	3.0*2	230/380/415	50/60	9800	1680	1200
MB200	20.0	56.0	5.5*2	230/380/415	50/60	11800	1680	1500





Machine running condition: water temperature 23°C, evaporate temperature -12°C,condensing temperature 40°C, reference valve under 50Hz power condition. Real production of machine will have a little change according to change of water temperature and ambient temperature.





Note: the size of machine for reference only, for different block ice size design, machine's size will be different.



Kindly confirm your requirement for each ice block design and power form of the size for install and use the machine.
