WG3064 64-Channel Rack-Mount Optical Power Meter-1U, 850-1625nm, 0.1dB, USB/LAN, for 1.6T Optical Module & Silicon Photonics Parallel Testing

The WG3064 is a 64-channel, 1U rack-mount optical power meter engineered for the density and throughput demands of next-generation optical module production. Its 64 independent input channels acquire simultaneously with no channel-to-channel time skew, eliminating the polling bottleneck that limits conventional switched test setups and enabling >300% test-efficiency gains versus single-port or low-channel-count instruments. Each channel supports independent wavelength calibration across 9 common windows from 850nm to 1625nm, a decisive advantage when a single rack must simultaneously verify ports configured for different wavelengths. The InGaAs detector delivers ±0.1dB accuracy, 0.01dB resolution, with dual-range coverage of −70 to +10 dBm (Type A) for weak-signal sensitivity or −50 to +26 dBm (Type B) for high-power tolerance. USB and LAN interfaces with open SCPI-style protocol support full program control, and the included host software enables seamless ATE integration. Purpose-built for 400G/800G/1.6T transceiver production, silicon photonics/CPO array characterization, and passive component batch IL testing, the WG3064 fits standard 1U rack space (450×360×132mm, approx. 4kg) with AC 100–250V universal input.
